Turbo Levo 4 Expert
Technical Specifications
Description
E-System - Specialized 3.1 Motor w/ 666 Watts & 101 Nm, 840 Wh Battery, up to 5.33 hour range
Frame - FACT 11m Carbon, Geo Adj & SWAT Storage
Suspension - Front: 160mm FOX 38 Performance Elite GRIPX2, Rear: 150mm GENIE - FOX FLOAT X Performance Elite
Drivetrain - SRAM GX Eagle T-Type AXS
Wheels - Roval Traverse Alloy / DT 370
Frameset
Frame All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm
Seat Binder Alloy, 38.6mm
SWAT SWAT internal downtube storage
Suspension
Fork FOX 38 Performance Elite series, 29", GRIP X2 damper,15x110mm axle, 44mm offset, 160mm of travel
Cockpit
Seat Post PNW Loam post w/travel adjust S2: 125mm, S3: 170mm, S4/S5/S6: 200mm
Saddle Bridge Comp, Hollow Cr-mo rails
Stem Alloy Trail Stem, 35mm bar bore
GripsDeity Lockjaw grips
Handlebars Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
Brakes
Front Brake SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm Rotor
Rear Brake SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm rotor
Drivetrain
Shift Levers SRAM AXS POD Controller
SRAM GX Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery). SRAM GX Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).
Cassette SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
Crankset SRAM GX Eagle Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm
Chain SRAM GX Eagle Transmission Flattop Chain
Chain Ring SRAM 34t T-Type chainring, 104 BCD, steel
eBike
Battery 840Wh battery
Charger Specialized 4amp charger
Motor All New Specialized 3.1 Motor, 101Nm torque, 666W power
UI Remote All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app
Wheels & Tyres
Front Wheel Roval Traverse Alloy 29", DT Swiss 370, 15x110mm, 28h
Rear Wheel Roval Traverse Alloy 27.5", DT Swiss 370 XD freehub body, 12x148mm, 32h
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
Tubes Standard, Presta valve
Accessories
