Turbo Levo 3 Pro Carbon
95223-1006
Pairs well with
Pickup available from our South Melbourne Showroom
Free Shipping on Orders over $200, excludes bikes.

Turbo Levo 3 Pro Carbon
Technical Specifications
Description
The MasterMind Turbo Control Unit is your information hub with customizable display fields, including the exact percentage of battery level, and it features our all-new MicroTune function to adjust power delivery in 10% increments, so you get exactly the support you need to experience precisely the ride you want.
A dedicated mixed-wheel size design with a 27.5” wheel in the back and 29” up front delivers a nimble ride that carves circles around other full-power e-MTBs. A generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack headtube angle and reduced fork offset keep things stable in the rough.
Levo offers six distinct geometry settings, allowing you to easily dial-in its performance for any riding style andany terrain. Head tube angle can be adjusted between 63- and 65.5-degrees. Bottom bracket height can be fine-tuned up or down by 7mm.
Levo’s 150mm of rear travel is supple on small bumps, devours square-edged hits without a twitch, eats massive G-outs for breakfast, yet still offers amazing pedal response and delivers your power to the ground with total efficiency.
The Levo’s S-Sizing is based on what matters—rider size and style, not inseam. Six sizes, all with similar headtube lengths and standover, allow you to choose the size that best suits your individual style. Smaller S-Size numbers are going to be nimble and more flickable, while bigger S-Sizes deliver more stability and a roomier ride.
Frameset
Frame FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
Seat Binder Alloy, 38.6mm
SWAT SWAT CC steerer tube integrated tool with chain tool and link
Suspension
Fork Fox 38 Factory, Grip 2 damper, 29", 160mm travel, Kashima, 44mm offset
Cockpit
Seat Post Bike Yoke Revive dropper Post, 34.9mm diameter, S2/S3: 160mm, S4/S5: 185mm, S6: 213mm
Saddle Bridge, 155/143mm, Hollow Ti-rails
Stem Deity, 35.0mm
GripsDeity Lockjaw Grips
Handlebars Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm
Brakes
Front Brake SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 220mm
Rear Brake SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm
Drivetrain
Shift Levers SRAM AXS POD Controller
Rear Derailleur SRAM X0 Eagle Transmission
Cassette SRAM X0 Eagle Transmission Cassette, 12spd, 10-52t
Crankset Praxis Carbon/Custom Offset/ISIS Spindle Interface, 160mm
Chain SRAM X0 Eagle Transmission Flattop Chain
Chain Ring SRAM Eagle Transmission 34t Steel, 104BCD
eBike
Battery Specialized M3-700, Integrated battery, 700Wh
Charger Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Motor Specialized 2.2 Custom Rx Trail Tuned Motor, 90Nm Torque, 565W Power
UI Remote Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
Wiring Harness Custom Specialized wiring harness
Wheels & Tyres
Front Wheel Roval Traverse Carbon 29
Rear Wheel Roval Traverse Carbon 27.5
Front Hub DT Swiss 350, sealed cartridge bearings, 15x110mm spacing, 28h
Rear hub DT Swiss 350, Star Ratchet, 36t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6" Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6" Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Tubes Standard, Presta Valve
