Technical Specifications

Description
With seven wins at Paris-Roubaix, our Roubaix has proven that Smoother is Faster. Until this moment, however, smooth has admittedly come with some compromises. But not anymore. The all-new S-Works Roubaix now delivers compliance without compromise by introducing a radical new Future Shock 2.0 that gives you more control and damping options, a new Pavé seatpost that creates our most balanced Roubaix to date, aerodynamics that equal the Tarmac, and a Rider-First Engineered™ frame that tips the scales below 900 grams (Size: 56cm, Black). Is it still comfortable? Sure, but don’t call it a comfort bike, because performance was behind every engineering decision we made. This is the new Roubaix. You wanted the best bike money can buy, and this S-Works delivers. We spec’d it with the full Shimano Dura-Ace Di2 12-speed groupset, our World-Tour-level Roval Alpinist CLX carbon fiber wheels, the all-new S-Works Pavé seatpost, and S-Works from head-to-toe on everything from the Power saddle to the 28mm Turbo Cotton tires. It’s absolute perfection. The new frame delivers compliance without compromise via the perfect balance of aerodynamics, light overall weight, compliance, and Rider-First Engineering. With tube shapes that were born in our FreeFoil Shape Library and validated in the Win Tunnel, the new Roubaix is more aero than the Tarmac SL6. Meanwhile, to ensure the weight and ride quality, we turned to a Rider-First Engineered™ design to deliver optimal stiffness and compliance across all sizes, from 44 to 61cm. Of course, the frame also stays below 900 grams (Size 56cm

Black). And to prep you for your own Hell of the North, we’ve made room for 33mm tires.

To go along with the new frame, we’ve also developed a totally-new S-Works Pavé seatpost. Not only is it the first compliant seatpost that’s also aerodynamic, it does so without any additional weight or finicky contraptions. Starting with the same D-shape design found on the Tarmac, we took its compliance a step further by building additional flex into the upper and developing a new drop-clamp design in the frame. This provides plenty of compliance, while staying perfectly balanced with the front-end, so you get a smooth, balanced ride no matter how rough the road.

The Future Shock 2.0 is the result of our pro riders’ demands for the cobbles of Roubaix. It’s smoother, faster, and gives you more control via a knob atop the stem. This knob adjusts compression from fully-open to stiff, while hydraulically-damped internals control rebound. Add it up, and this latest version will reduce fatigue and increase your speed, no matter the terrain. The new Smooth Boot, top cap, and Future Stem also enhance the aesthetic, so you get a clean transition from head tube to stem.













Frameset

Frame FACT 11R, Rider First Engineered™ (RFE), FreeFoil Shape Library tubes, threaded BB, 12x142mm thru-axle, flat-mount disc

Seat Binder Hidden drop clamp

Suspension

Fork Future Shock 2.0 w/ Smooth Boot, 12x100mm thru-axle, flat-mount disc

Cockpit

Seat Post S-Works Pave

Saddle Body Geometry S-Works Power, carbon fiber rails, carbon fiber base

Stem S-Works Future Stem w/ Integrated Computer mount

S-Works Carbon Hover Drop 125mm, Reach 75mm, w/Di2 hole S-Works Carbon Hover Drop 125mm, Reach 75mm, w/Di2 hole

Brakes

Front Brake Shimano Dura-Ace R9270, hydraulic disc

Rear Brake Shimano Dura-Ace R9270, hydraulic disc

Drivetrain

Shift Levers Shimano Dura-Ace R9270, hydraulic disc

Rear Derailleur Shimano Dura-Ace R9250, 12-speed

Cassette Shimano Dura-Ace, 12-speed, 11-34t

Crankset Shimano Dura-Ace R9200, HollowTech II, 12-speed with 4iiii Precision Pro dual-sided powermeter

Chain Shimano Dura-Ace, 12-speed

Chain Ring 32T

Bottom Bracket Shimano Dura-Ace, BB-R9100

Wheels & Tyres

Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes

Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes

Front Tire Turbo Cotton, 700x28

Rear Tire Turbo Cotton, 700x28

Tubes Presta, 48mm valve

Accessories
