Technical Specifications

Description
Turbo Levo SL is a new, lightweight breed of eMTB that harnesses the quick and lively ride of our Stumpjumper...and adds just enough power to introduce a whole new dimension of kick ass. The top-shelf S-Works Turbo Levo SL features a carbon chassis mated to FOX Factory-level suspension and SRAM's premier Eagle XX1 AXS drivetrain. IT'S YOU... JUST GOING FASTER...AND FURTHER The Turbo Levo SL is effectively a Stumpjumper that lets you embark on ridiculously long adventures with no fear of bonking and helps you snag three laps of your favorite trail instead of just one. Looking for a ton of power and range? Check out our Levo and Kenevo models. Want a bike, on the other hand, that simply feels like you—a faster you, with the power to ride more trails, kind of you? That's Turbo Levo SL. TUNE IT TO YOUR STYLE By connecting with our Mission Control App, you can tune the SL 1.1 motor to your riding style, record rides, and monitor the battery. The motor even has a built-in power meter that transmits to any ANT+ head unit. Don't want to connect? No worries—the simple Turbo Connect Unit (TCU) on the top tube gives you all the control you need to just climb on and ride all day. • Lightweight, carbon Stumpjumper-inspired frame is pure ride quality and control. • Ultra-smooth and lightweight SL 1.1 motor doubles your pedaling power. • 150mm of suspension front and rear, courtesy of FOX's Factory 36 fork and DPX2 shock. The Turbo Levo SL looks like a Stumpjumper and, out on the trail, feels like one too. That’s no mistake. We aimed to build a Stumpjumper with a bit more boost to it and that’s exactly what you get—a Sidearm chassis with just the right amount of front-to-rear stiffness and 150mm of smooth, custom-tuned FOX rear suspension. To top it all off, we constructed this Turbo Levo SL chassis entirely from our light-yet-strong FACT 11m carbon.

The lightweight SL 1.1 motor doubles your effort with as much as 240 watts of silent and powerful assistance to your pedals. The motor’s responsive torque curve delivers power perfectly in-tune with your normal riding cadence and leaves no resistance when you’re riding without power assistance.

Worried about running out of power? No problem. Turbo Levo SL eats up big miles and long days. And if you’re looking for even more miles, our included range extender boosts your range by another 50 percent. On top of all that, our Mission Control App can handle battery management automatically, ensuring your battery will last as long as you need it to.

Assist up to 20 mph / 32 km/h











Frameset

Frame FACT 11m full carbon, 29 Trail Geometry, Integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel

Seat Binder Alloy, 38.6mm

Suspension

Fork Fox Float 36 Factory, Grip2 damper, 150mm, 51mm rake, HSC, LSC, HSR, LSR, Kabolt axle

Cockpit

Seat Post RockShox Reverb AXS, 30.9mm, S: 125, M:150, L/XL: 170mm

Saddle Bridge, 155/143mm, Hollow Ti-rails

Stem Deity, 35.0mm

GripsDeity Knucklebuster

Handlebars Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm

Brakes

Front Brake Magura MT7 with custom Loic lever blade, 203mm rotor

Rear Brake Magura MT7 with custom Loic lever blade, 203mm rotor

Drivetrain

Shift Levers SRAM AXS Eagle Controller

Rear Derailleur SRAM XX1 Eagle AXS

Cassette Sram XG-1299, 12-Speed, 10-52t

Crankset Praxis Carbon/M30 Spindle Interface

Chain SRAM XX1 Eagle

Chain Ring SRAM X-Sync Eagle, 94 BCD, 30T

eBike

Battery Specialized SL1-320, fully integrated, 320Wh

Charger Custom charger, 48V System w/ SL system charger plug

Motor Specialized SL 1.1, custom lightweight motor

UI Remote Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote

Wiring Harness Custom Specialized wiring harness w/ chargeport

Wheels & Tyres

Front Hub Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing

Rear hub Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing

Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3" Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3"

Eliminator, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.3" Eliminator, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"

Spokes DT Competition Race

Tubes Standard, Presta valve

Accessories
